Laser Cut Carrier Box Generator

A shallow caddy with a centre divider that doubles as a carrying handle. Set the size, the grip cut-out and the number of extra separators.

Presets

Size

Inside width

Along the carry divider.

Inside depth

Front to back; the divider splits it in half.

Wall height

Carry divider

Divider length

Rise above the walls

For bottles, about two thirds of the bottle height above the walls.

Grip hole

Grip width

About 90 to 110 mm fits a hand.

Grip height

Grip from the top

Wood above the hole; this is what you lift by.

Compartments

Cross separators

Joints

Finger width

0 picks about twice the material thickness.

Material

Material thickness

Kerf

Enter your real sheet thickness; 3 mm plywood is often 2.8 to 3.2. Cut a test corner before the full box.

Personalize

Engrave a name, monogram, message or your own logo on any face. Preview it here for free.

+ Add logo / image

Your first carrier box download is free, engraving included.

Fits on 547mm x 362mm sheet (21.5" x 14.3")

Stand the separator in the bottom first, then lower the carry divider over it: the cross-lap slots meet at half the wall height.
Push the carry divider into the bottom; its end tabs go through the end walls when you fit them.
Glue the front and back to the bottom, then slide the end walls on from the ends.
Test-cut a separator and a strip of the bottom first: the tabs should push in by hand. Adjust the kerf if they are loose or will not go in.

The parts need a bed of about 547 x 362 mm. Check it against your laser, or cut in two sheets.

Drag an engraving in the preview to move it.

Good for

Bottle and condiment carriers
Cutlery caddies for picnics and parties
Plant and craft carriers

How it works

Set the size. Pick a preset or type your own measurements. Every box is drawn to your real material thickness.
Personalize it. Add a name, a message or an image, drag it into place, and see it on the box before you download.
Download and cut. The SVG imports at true size in LightBurn, xTool Creative Space and Glowforge. Cut a test corner first if you are unsure of your kerf.

FAQ

How is the divider fixed?

It locks into slots in the walls, so it is held without glue and can still be glued for a permanent box.

Can the separators be shorter?

Yes. Choose full-width dividers, or short half-width separators across the middle.

How much does it cost?

Your first download of each box type is free, engraving included. After that, 10 exports are $5, or $19 unlocks unlimited downloads for life. An export covers both the SVG and the DXF of the same design, and downloading it again is free.

Does it work with LightBurn, xTool, Glowforge and OMTech?

Yes. The SVG is in millimetres and imports at true size. Cut lines are red and engraving is filled black. The DXF is R12 for RDWorks and CAD software.

What kerf should I use?

Start with 0.15 mm for a CO2 laser or 0.08 mm for a diode, and cut a test corner. Every part is drawn half a kerf oversize so the joints press-fit.

Are my designs and logos uploaded?

No. The boxes, the engraving and any image you add are all handled in your browser. A saved draft stays on your device so your work survives signing in and checking out.
